Attaching and removing Case IH L front loaders require just a few simple steps and a single trip from the cab. This is made possible by the automatic locking FITLOCK 2+ System®, which allows instant hitching and unhitching of the loader with a dual safety lock. Your safety is our priority, which is why a locking status indicator is clearly visible to from the driver's seat. Once hitched, the MACH System® lets you to safely connect all hydraulic and electrical lines with one move.
L FRONT LOADERS
The new loader line-up by Case IH has expanded our horizons: three ranges and 27 models in total have been developed with a clear focus on our customers’ needs. Each loader is perfectly designed for use with our various tractor models and will leave you amazed. Benefit from maximum precision, rapid response and capacities next level – for exceptional ease of handling!
A-Series: Simple and reliable
Suiting tractors from the Farmall C up to the Maxxum, these entry-level loaders are equipped with mechanical self-levelling as standard, and the FITLOCK 2M System® for fast loader hitching/unhitching. Maximum lift heights on these models range from 3.5 m up to 4.0 m, while maximum lift capacities start at 1,330 kg and top out at 1,750 kg.
U-Series: Versatile and durable
The U front loader range with mechanical self-levelling is ideal for everyday handling tasks. Matching Case IH tractors from the Farmall C to the Puma 175 CVXDrive, they are easy to operate and are offered with the FITLOCK 2+ System® for quick hitching/unhitching. 4 models can be specified with non self levelling system. Lift heights on these models max out at 3.50m to 4.50m, while maximum lift capacities start at 1,210kg and top out at 2,230kg.
T-Series: High-output work
The flagship T range is a premium specification range including hydraulic self-levelling as standard to increase the lifting power by 35%. This series fits Case IH tractor models from the Farmall 55C to the Puma 240. The ten loader models include features such as hydraulic hose routing through the loader frame and cross-bar to prevent damage. Maximum lift heights on these models range from 3.75m to 4.7m, with lift capacities from 1,390kg to 2,720kg.
Explore the series
- With the FAST-LOCK System® (a T and U series exclusive), implements can be locked and unlocked, by simultaneously pressing two buttons. Changing implements has become fast and easy.
- The MACH 2® feature is a real asset when it comes to keeping the job simple. One move is all it takes to instantly multi-couple loader and implement hydraulics. Ideally located on the carrier, the unit prevents any wear of the hoses between the tool and the loader while its flat seal design prevents oil leaks.
- Enjoy greater comfort with the AUTO-UNLOAD System® option which synchronises grab-opening and bucket-dumping functions by opening the grab and tipping the bucket at the same time.
- The SHOCK ELIMINATOR uses hydraulics to absorb shocks experienced during driving, handling heavy implements or by sudden stops. This also server to protect your tractor from impacts, jolts, physical shocks and vibrations. Of course, a smoother ride also increases your comfort as a driver.
- The front loader is perfectly matched to the tractor's design with a bracket position very close to it's center of gravity. This gives Case IH loaders an exceptional forward reach for discharging and a more convenient position to load a trailer or mixer.
- Every front loader series has an accurate and easily visible implement position indicator at all lifting heights. You always know the angle of the attachment in relation to the ground. The position of the tilt indicator can be customized to your preferences without any specialized tool.
- On the A and U series, the parking stands are integrated into the loader arms and have their own simple and effective locking/ unlocking mechanism. The T series loader's parking stands fold away into the arm profile so as not to compromise lift height. An automatic locking mechanism allows faster operation and minimum downtime.
