L103 For Farmall Medium Utility C
Designed for the Farmall® medium utility C series tractors
- Max Lift Capacity: up to 3,241 lb. (1 470 kg)
- Max Height: up to 129 in. (3 270 mm)
- Boom Breakout Force: up to 3,417 lb. (1 550 kg)
L10 Series Loaders
Faster Cycle Times for More Productive Work Days
L10 series loaders have the features to make livestock feeding, material handling and other loader work more efficient. Faster cycle times, due to faster hydraulics or the ability to see better and move more nimbly, help you get more work done, quicker.
Available Models
L103 for Farmall 100A Series
Designed for Farmall® large utility 100A series tractors
- Max Lift Capacity: up to 2,094 lb. (950 kg)
- Max Height: up to 133 in. (3 370 mm)
- Boom Breakout Force: up to 3,020 in. (1 370 kg)
L103 for Maxxum series
Designed for Maxxum® series tractors with 2WD front axles
- Max Lift Capacity: up to 2,381 lb. (1 080 kg)
- Max Height: up to 131 in. (3 330 mm)
- Boom Breakout Force: up to 3,439 in. (1 560 kg)
L103 for Vestrum series
Designed for Vestrum® series tractors
- Max Lift Capacity: up to 3,505 lb. (1 590 kg)
- Max Height: up to 143 in. (3 640 mm)
- Boom Breakout Force: up to 3,682 lb. (1 670 kg)
L104
Designed for Farmall® large utility 100A series tractors
- Max Lift Capacity: up to 3,814 lb. (1 730 kg)
- Max Height: up to 139 in. (3 530 mm)
- Boom Breakout Force: up to 3,968 lb. (1 800 kg)
L105
Designed for Maxxum® series tractors.
- Max Lift Capacity: up to 5,203 lb. (2 360 kg)
- Max Height: up to 150 in. (3 810 mm)
- Boom Breakout Force: up to 5,975 lb. (2 710 kg)
L106
Designed for Puma® 150, 165 NS 175 tractors.
- Max Lift Capacity: up to 5,578 lb. (2 530 kg)
- Max Height: up to 154 in. (3 920 mm)
- Boom Breakout Force: up to 6,415 lb. (2,910 kg)
L107
Designed for Puma® 185- 260 tractors.
- Max Lift Capacity: up to 5,622 lb. (2 550 kg)
- Max Height: up to 168 in. (4 270 mm)
- Boom Breakout Force: up to 6,768 lb. (3 070 kg)
L108
Designed for Case IH Magnum™ 180 to 240 series tractors
- Max Lift Capacity: 6,151 lb. (2 790 kg)
- Max Height: 162 in. (4 110 mm)
- Boom Breakout Force: 8,620 lb. (3 910 kg)
Compatibility
Compatible Tractors
L103
Compatible with:
Farmall Medium Utility C: 90C, 100C, 110C, 120C
Farmall Medium Utility U: 110U, 120U
Farmall Large Utility 100A: 110A, 120A, 130A, 140A
Vestrum: 100, 130
Maxxum: 115, 125, 135, 145, 150
L104
Compatible with:
Farmall Large Utility 100A: 110A, 120A, 130A, 140A
L105
Compatible with:
Maxxum: 115, 125, 135, 145, 150
L106
L107
Compatible with:
Puma: 185, 200, 220, 240
L108
Compatible with:
Magnum: 180, 200, 220, 240
View Specs
Self-Levelling Feature | |||||||||
Self-Levelling | |||||||||
Tractor Compatibility | |||||||||
Lift Capacities | |||||||||
Lift Height Dimensions, Fully Raised | |||||||||
Boom Lift Breakout Force | |||||||||
Bucket Rollback Force | |||||||||
Horizontal Reach Distance | |||||||||
Dump And Rollback Angles | |||||||||
Digging Depth | |||||||||
Weight | |||||||||
Couplers For Buckets And Attachments | |||||||||
Hydraulic Function, Ride And Detachable Features | |||||||||
