Heavy Offset Disk Harrows

Case IH Heavy-Offset disk harrows perform an array of soil-conditioning tasks with tough, long-lasting components. Our offset disk harrows can be custom equipped with three disk blade sizes and spacing configurations to easily deep-till stalks and stubble, bury brush and level irrigated fields.

Get a quote
Case IH Heavy Offset disk harrows
Working Width

11' 1" - 27' 2"

Transport Width

11' 1" - 22' 7"

Disk Blade Diameter

28" or 32"

Disk Blade Spacing

10.5" or 12"

Heavy Offset Disk Harrows



    Get a quote

    Unmatched Ruggedness, Dependability and Performance

    Case IH Heavy-Offset 790 disk harrows are engineered to provide consistent performance over years of use. Featuring durability-enhancing design, adjustability to fit varying conditions and self-sharpening Earth Metal® blades.

    Download brochure

    Explore the series

    • Offset-Disk-Harrow-790_5066_05-10

      Designed for Durability

      The Case IH Heavy-Offset disk harrows are designed to handle even the toughest conditions.


      • Welded steel tubing for stability in the field and during transport
      • Nodular iron spools resist compression up to 20 tons without loosening blades
      • High-capacity bearings featuring Cushion Gang® flange bearings
      • Self-leveling hitch keeps gangs working at uniform depth


    • Heavy_offset_790_feature_2

      Unlike steel-fabricated spools on other brands, Case IH cast nodular iron spools:
      - Resist compression up to 20 tons without loosening blades
      - Add greater blade support with bell-shaped design
      - Provide better residue flow with hourglass middle
    • Heavy_offset_790_feature_3

      Flangent and Cushion Gang® bearings feature:
      - Finely ground inner rings
      - Heavy steel sleeves that distribute shock loads along the arbor bolt

      All bearings are: - Regreasable for extended life
      - Triple sealed to repel debris and moisture
    • Heavy_offset_790_feature_2

      - Gang angle: Adjustable from 34 – 46 degrees; Adjusts without tools
      - Rear gangs: Adjust laterally to changing field conditions; Line up with front gang furrows as desired
      - Easy-turning crank; Fine-tunes front-to-rear leveling
